Unreal Engine Data Systems

Modern game development requires robust data handling, from local persistence to remote API integration.

Save and Load Game C++

Unreal’s USaveGame is the backbone of persistence. The common pattern is:

1. Try LoadGameFromSlot.
2. If it doesn’t exist, create it with CreateSaveGameObject.
3. Update values in memory as the user plays.
4. Persist the final state with SaveGameToSlot (often from an Apply button or a checkpoint).

YourSaveGameClass.h

#pragma once

#include "CoreMinimal.h"
#include "SettingsDataStruct.h"
#include "GameFramework/SaveGame.h"
#include "YourSaveGame.generated.h"

UCLASS()
class YOURGAME_API UYourSaveGame : public USaveGame
{
    GENERATED_BODY()

public:
    UPROPERTY(VisibleAnywhere, Category = "Save Game Data")
    FSettingsDataStruct SettingsData;
};

Load + Create (if missing)

const FString SlotName = TEXT("YourGameSlot");

UYourSaveGame* SaveGameData = Cast<UYourSaveGame>(UGameplayStatics::LoadGameFromSlot(SlotName, 0));
if (!SaveGameData)
{
    SaveGameData = Cast<UYourSaveGame>(UGameplayStatics::CreateSaveGameObject(UYourSaveGame::StaticClass()));
}

Save

if (SaveGameData)
{
    SaveGameData->SettingsData.VsyncQuality = TEXT("on");
    UGameplayStatics::SaveGameToSlot(SaveGameData, SlotName, 0);
}

Tip: If you’re saving large data (inventories, world state), consider async save/load to avoid hitches.

Using DataTable C++

DataTables are the fastest way to move “tweakable values” out of code. A common workflow is to store default game settings (graphics/audio) in a CSV, then import it as a DataTable.

Example CSV

Note: The first column must be named Name.

SettingsDataStruct.h

#pragma once

#include "Engine/DataTable.h"
#include "SettingsDataStruct.generated.h"

USTRUCT(BlueprintType)
struct FSettingsDataStruct : public FTableRowBase
{
    GENERATED_USTRUCT_BODY()

public:
    FSettingsDataStruct()
        : ScreenResolution(TEXT("1920x1080"))
        , ViewDistance(TEXT("Far"))
        , AntiAliasing(TEXT("Epic"))
        , ShadowQuality(TEXT("Ultra"))
        , TextureQuality(TEXT("Ultra"))
        , VsyncQuality(TEXT("on"))
        , MasterVolume(1.0f)
        , MusicVolume(1.0f)
    {}

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    FString ScreenResolution;

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    FString ViewDistance;

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    FString AntiAliasing;

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    FString ShadowQuality;

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    FString TextureQuality;

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    FString VsyncQuality;

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    float MasterVolume;

    UPROPERTY(EditAnywhere, BlueprintReadWrite, Category = "Settings Data")
    float MusicVolume;
};

Import

• In Content Browser: right-click -> Import -> choose your CSV.
• When asked for the row struct: select FSettingsDataStruct.
• The resulting DataTable can be read in C++ or Blueprints.

API/Json Usage

Connecting your game to a web service allows for online leaderboards, remote profiles, or dynamic content.

First, add the required modules to your *.Build.cs:

PrivateDependencyModuleNames.AddRange(new string[] { "Http", "Json", "JsonUtilities" });

HttpTest.h

#include "Http.h"
#include "CoreMinimal.h"
#include "GameFramework/Actor.h"
#include "HttpTest.generated.h"

USTRUCT()
struct FPlayerData
{
  GENERATED_BODY()
  UPROPERTY()
  FString title = "foo";
  UPROPERTY()
  FString body = "bar";
  UPROPERTY()
  int16 userId = 1;
};

UCLASS()
class API_API AHttpTest : public AActor
{
    GENERATED_BODY()

private:
  FHttpModule* Http;
  void PostArea();
  void OnProccessRequestComplete(FHttpRequestPtr Request, FHttpResponsePtr Response, bool Success);

public:
  virtual void BeginPlay() override;
};

HttpTest.cpp

void AHttpTest::BeginPlay()
{
  Super::BeginPlay();
  Http = &FHttpModule::Get();
  PostArea();
}

void AHttpTest::PostArea()
{
     // Create Request
     TSharedRef<IHttpRequest, ESPMode::ThreadSafe> Request = Http->CreateRequest();

     // Bind to callback
     Request->OnProcessRequestComplete().BindUObject(this, &AHttpTest::OnProccessRequestComplete);

     // --- GET Request ---
     // Request->SetURL("https://jsonplaceholder.typicode.com/posts");
     // Request->SetVerb("GET");

     // --- POST Request ---
     Request->SetURL("https://jsonplaceholder.typicode.com/posts");
     Request->SetVerb("POST");
     Request->SetHeader("Content-Type", TEXT("application/json"));

     // Serialize Struct to JSON String
     FString JsonString;
     FPlayerData PlayerData;
     FJsonObjectConverter::UStructToJsonObjectString(PlayerData, JsonString);

     Request->SetContentAsString(JsonString);

     Request->ProcessRequest();
}

void AHttpTest::OnProccessRequestComplete(FHttpRequestPtr Request, FHttpResponsePtr Response, bool Success)
{
  if (Success)
  {
     UE_LOG(LogTemp, Warning, TEXT("%s"), *Response->GetContentAsString());
  }
  else
  {
     UE_LOG(LogTemp, Warning, TEXT("Request Failed!!!"));
  }
}

Asset Manager

The Asset Manager is a powerful system for discovering and loading assets like items, characters, or maps without blocking the game thread.

1. Define Primary Asset Types: Use FPrimaryAssetType to categorize your items.
2. Configuration: Update DefaultEngine.ini to set the AssetManagerClassName.
3. Loading: Use StreamableManager to load assets in the background.

// Retrieving items via Asset Manager
TArray<FPrimaryAssetId> IdList;
AssetManager.GetPrimaryAssetIdList(ItemType, IdList);
AssetManager.LoadPrimaryAssets(IdList, ...);

Gameplay Ability Plugin

The Gameplay Ability System (GAS) is a robust framework for building combat mechanics and RPG systems.

• Attributes: Health, Mana, Stamina.
• Abilities: “Jump,” “FireBall,” “Dodge.”
• Gameplay Effects: Damage over time, Buffs, Debuffs.

For complex projects, GAS manages the replication and execution of these features automatically, ensuring consistency between server and client.
